Basic Info.
Model NO.
T1 T2 T3 T4
Bearing Bar Pitch
15 to 60mm, Customized
Cross Bar Pitch
50 to 100mm, Customized
Bearing Bar Dimension
20*3 to 65*5mm, Various Dimension
Certificate Quality
ISO9001
Bearing Bar Type
Serrated, I Type, Plain
Place of Origin
Hebei Anping
Company Name
Hebei Jiuwang Metal Wire Mesh Co.Ltd
Transport Package
According to Customer′s Need
Specification
G325/40/100
Trademark
JIUWANG
Origin
Hebei Anping
HS Code
730890000
Production Capacity
100000sqm
Packaging & Delivery
Package Size
100.00cm * 25.00cm * 3.00cm
Package Gross Weight
15.000kg
Product Description
panel size available(black grating): 1000x5800mm or 1000x6000mm
Bearing bar pitch | Cross bar pitch | load steel size ( Width ×Thickness) | |||||
20×3 | 25×3 | 32×3 | 40×3 | 20×5 | 25×5 | ||
30 | 100 | G203/30/100 | G253/30/100 | G323/30/100 | G403/30/100 | G205/30/100 | G255/30/100 |
50 | G203/30/50 | G253/30/50 | G323/30/50 | G403/30/50 | G205/30/50 | G255/30/50 | |
40 | 100 | G203/40/100 | G253/40/100 | G323/40/100 | G403/40/100 | G205/40/100 | G255/40/100 |
50 | G203/40/50 | G253/40/50 | G323/40/50 | G403/40/50 | G205/40/50 | G255/40/50 | |
60 | 50 | - | G253/60/50 | G253/60/50 | G403/60/50 | G205/60/50 | G255/60/50 |
Bearing bar pitch | Cross bar pitch | load steel size (Width ×Thickness) | |||||
32×5 | 40×5 | 45×5 | 50×5 | 55×5 | 60×5 | ||
30 | 100 | G325/30/100 | G405/30/100 | G455/30/100 | G505/30/100 | G555/30/100 | G605/30/100 |
50 | G325/30/50 | G405/30/50 | G455/30/50 | G505/30/50 | G555/30/50 | G605/30/50 | |
40 | 100 | G325/40/100 | G405/40/100 | G455/40/100 | G505/40/100 | G555/40/100 | G605/40/100 |
50 | G325/40/50 | G405/40/50 | G455/40/50 | G505/40/50 | G555/40/50 | G605/40/50 | |
60 | 50 | G325/60/50 | G405/60/50 | G455/60/50 | G505/60/50 | G555/60/50 | G605/60/50 |
steel grating standard-- 325 steel grating
Steel Grating Standard | |||
Steel Grating Standard | Steel Standard | Galvanizing Standard | |
China Standard | YB/T 4001.1-2007 | GB700-88 | GB/T13912-2002 |
USA Standard | ANSI/NAAMM (MBG531) | ASTM (A36) | ASTM (A123) |
U.K. Standard | BS4592 | BS4360 (43A) | BS729 |
Australia Standard | AS1657 | AS3679 | AS1650 |
Deutsche Standard | DIN24537 | DIN17100-80 | DIN50976 |
Application:
Steel grating, with robust design and spanning abilities, is very strong and safe for
The support of floors and elevated walkway. It can be used for ceiling, interior
Decoration, decoration, platform aisle, ventilation windows, (Wells), advertising
Plaque and other construction.
Fields of Application:
Light chemical industry, Petrol-chemistry, Machinery industry, Textile chemistry,
Port engineering, Oil and grease chemistry, Agriculture husbandry, Horticulture,
Steel industry, Waste disposal, Food processing, Aquatic breeding, Fertilizer
Industry, Pharmaceutical industry, Parking lots, Cement plants, Oil refinery,
Mining and refinery, Power plants, Public utility, Marine engineering, Shipbuilding,
Construction material industry, Defense projects, Airport projects, Water plants,
Sewage disposal, Paper and pulp industry, Construction industry, Transportation
Industry, Automotive industry
Materials:
Mild carbon steel provides an economical, high strength for uses in most industrial
And commercial applications.
Advantages:
Steel grating offers the following advantages compared with steel grid sheets:
Steel grating has light weight, good strength, large carrying capacity and can save
Materials and cost. It offers good ventilation of light and wind, a modern sense,
Aesthetic appearance and anti-skid safety. It is also easy to clean,
Easy to installation and durable for uses.
